FL CW Series｜PM fiber laser with Frequency convertor
Product Overview
Frequency conversion laser based on single pass configuration from CW fiber laser. Since there are no cavities at frequency conversion stage, it is rather stable even under the fluctuated environment. Residual fundamental light is also dumped outside the convertor, there are no heating materials at laser head. By another approach, It is also available dual/triple wavelength out from one laser unit.
Features
Compact head
Fundamental light is delivered by PM fiber, laser head is relatively compact.
No heat sink
Residual fundamental light is coupled into MMF and dumped at outside the convertor head, there are no heat source at the convertor and easy to integrate it into the system without cooling.
High reliability
Maintenance free by OXIDE’s spectacular quality crystals and the high stability fiber lasers. Optimization of nonlinear device and optical design realize compact reliable solution.
Customized wavelength is available
By adjusting the FBG in fiber laser and NLO device gratings at convertor, it is available to choose arbitrary wavelength within fundamental light of 1050 to 1090 nm range.
Applications
- Optical tweezers
- Particle imprecation
- Bio analysis
- Semiconductor inspection
- Optical component inspection
- Photoluminescence pump source
Frequency convertor’s Specifications
| Model | FL-CW-SHG | FL-CW-THG | FL-CW-3band |
| Image |  |
 |
 |
| Wavelength | 532 nm | 355 nm | 355・532・1064 nm |
| Output Power | 3 W | 30 mW | 30・400・3000 mW |
| Output Type | Free space | Free space | Free space |
| Extinction Ratio | > 100:1 | > 100:1 | > 100:1 |
| Beam Quality | TEM00, M2 < 1.2 | TEM00, M2 < 1.2 | TEM00, M2 < 1.2 |
| Polarization | Linear | Linear | Linear |
| Dimensions (Convertor) | 200x63x44 mm | 200x63x44 mm | 160x100x45 mm |
| Schematics |  |
 |
 |
| Features,Options, etc. |
|
|
|
FBG type CW-PM fiber laser
Features
Applications
|
Specifications
|
*Power supply is required to prepare separately.
Models with power supply are also available. Please feel free to contact us.
